Bison 016-562-0084 AC Gearmotor
The Bison 016-562-0084 is a 1/20 HP, 115 VAC gearmotor with a 84.3:1 ratio and 20 RPM output, rated 142 in-lb. Bison lists it as GEARMOTOR 1/20HP 115VAC/60HZ 84:1 RATIO.
| Part number | 016-562-0084 |
|---|---|
| Series | 562 1/20 HP PSC AC |
| Type | AC gearmotor |
| Horsepower | 1/20 HP |
| Voltage | 115 VAC |
| Output speed | 20 RPM |
| Output torque | 142 in-lb |
| Gear ratio | 84.3:1 |
| Approx. weight | 12 lb |
| Minarik / alternate part no. | 508-03-002 |
Specs from the Bison Gear price file. Confirm mounting, shaft and enclosure on the drawing before you order.
Need price or lead time on the 016-562-0084? Request a quote or book 15 minutes to review the application.
