109R Hammond Audio Transformer
Priced within one business day. Factory-direct pricing from an authorized rep. Replacing a competitor part? Send the number and we cross it.
Questions or Require Additional Information?
Call us Today at +1-248-830-4850
The Hammond Manufacturing 109R is listed by Hammond as audio transformer, potted, primary 10K ctohms , secondary 1.5K ct ohms, from the 2W Audio Miniature Epoxy Potted (109 Series). Applied Control is the Hammond manufacturers representative. Send the catalog number with the quantity, and the quote comes back the same business day.
Request a QuoteBook 15 Minutes
109R specifications
| Catalog number | 109R |
| Manufacturer | Hammond Manufacturing |
| Series | 2W Audio Miniature Epoxy Potted (109 Series) |
| Hammond description | Audio transformer, potted, primary 10K ctohms , secondary 1.5K ct ohms |
| Hammond short description | AUDIO TX POTTED |
| Shipping weight | 0.1 lb (0.05 kg) |
| Primary Nominal Impedance (Ohms) Pins 1-3 | 10K ct |
| Secondary Nominal Impedance (ohms) Pins 4-6 | 1.5K ct |
| Primary DCR (Ohms) +/- 20% | 700 |
| Secondary DCR (Ohms) +/- 20% | 150 |
| Max. D.C. Unbalance (ma.) | 1.5 |
| Compliance | REACH and RoHS |
Specifications from the Hammond Manufacturing product page for 109R. Confirm against the current Hammond drawing before you design it in.
Hammond product page for 109R · Hammond 109 series specification sheet (PDF).
