1599TABSBKBAT Hammond ABS Plastic Tablet Enclosure, 4.72 x 3.74 x 1.06 in, Black
Priced within one business day. Factory-direct pricing from an authorized rep. Replacing a competitor part? Send the number and we cross it.
Questions or Require Additional Information?
Call us Today at +1-248-830-4850
The Hammond Manufacturing 1599TABSBKBAT is listed by Hammond as enclosure, plastic, from the ABS Plastic Tablet Enclosures (1599TAB Series). Applied Control is the Hammond manufacturers representative. Send the catalog number with the quantity, and the quote comes back the same business day.
Request a QuoteBook 15 Minutes
1599TABSBKBAT specifications
| Catalog number | 1599TABSBKBAT |
| Manufacturer | Hammond Manufacturing |
| Series | ABS Plastic Tablet Enclosures (1599TAB Series) |
| Hammond description | enclosure, plastic |
| Hammond short description | FRABS SMALL TABLET W BAT |
| Size L x W x H | 4.72 x 3.74 x 1.06 in (120 x 95 x 27 mm) |
| Shipping weight | 0.22 lb (0.10 kg) |
| Material | ABS Plastic |
| Color | Black |
| Flame Rating | UL94 V-0 |
| Product Category | Enclosures |
| Type | Tablet, battery compartment |
| Max. P.C. Board Length (mm) | 87.94 |
| Max. P.C. Board Width (mm) | 97.95 |
| Compliance | REACH and RoHS |
Specifications from the Hammond Manufacturing product page for 1599TABSBKBAT. Confirm against the current Hammond drawing before you design it in.
Hammond product page for 1599TABSBKBAT · Hammond 1599TAB series specification sheet (PDF) · Plastic Chemical Resistance Statement 10-2023 (PDF) · 1599TABSBAT PCB.dwg.
